| Product Center > Socket > Audio Jack > 3.5 Audio socket SMD

Scan code to browse

3D fileXB-C-PJ01-05 Specifications XB-PJ
DrawingsXB-C-PJ01-05

▍Xibang material number：XB-C-PJ01-05

3D file and drawings

3D fileXB-C-PJ01-05 Specifications XB-PJ

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-C-PJ01-05 3D Drawings		3.5 Headphone socket Φ 3.5mm 4.0H 6PIN headphone socket L=13MM (short head), two locating posts		Normal	1-2 weeks	0.472	1000 pieces/bag	3000	10000	No competitive products	Consult

产品材质	terminal 1:	Phosphor Bronze,Gold
	terminal 2:	Phosphor Bronze,Gold
	terminal 3:	Phosphor Bronze,Gold
	terminal 4:	Phosphor Bronze,Gold
	terminal 10:	Phosphor Bronze,Gold
	terminal 11:	Phosphor Bronze,Gold
	plastic:	High Temp. Thermoplastic

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	5000
	Insertion force:	5–20 N
	Withdrawal force:	4–20 N

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	0.5 A
	Rated voltage:	30 V AC/DC
	Rated impulse voltage:	500 V/60 s
