| Product Center > Socket > Audio Jack > 6.35 Audio Jack

Scan code to browse

3D fileXB-CK-6.35-665BWT-2 Specifications XB-1
DrawingsXB-CK-6.35-665BWT-2

▍Xibang material number：XB-CK-6.35-665BWT-2

Product name: Audio socket Rated current: 0.5A 1A Rated voltage: 12V 30V DC Contact resistance: 30m Ω max

Insulation resistance: 100 M Ω min, withstand voltage: 500V AC, insertion and extraction force: 3N-30N, extraction force: 3N-15N

Service life: 5000 times Welding temperature: 250 ± 5 ℃ Installation method: Plugin Product certificate: ROHS

3D file and drawings

3D fileXB-CK-6.35-665BWT-2 Specifications XB-1

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-CK-6.35-665BWT-2 3D Drawings		Horizontal 6.35 audio connector/microphone 6.35 headphone jack/plug-in microphone 6.35 headphone jack/6.35mm audio jack/audio 6.35 audio jack/6.35 headphone base horizontal plug/plug-in 6.35 audio jack/6.35MM audio jack vertical		Normal	1-2 weeks	0.3g	1000 pieces/bag	5000	10000	No competitive products	Consult

Product material	1. Audio socket	material quality
	2. The lid	yellow metal
	3. Shrapnel	yellow metal
	4. The base	PBT/PA66/POM
	5. Touch	Brass / silver plated / gold plated
	6. Terminal	Brass / silver plated / gold plated

	Use the temperature range	-30°C±85°C
	Maximum rating (resistance load)	1A 30V
	Minimum rating (resistance load)	0.5A 12V

Electric performance	withstand voltage	500V AC
	insulation resistance	100mΩ max

lasting quality	No load life	5000 Times
	load life	5000 Times

Environmental resistance	Cold resistance	-40±3℃ for 96h
	resistance to effect of heat	80±2℃ for 96h
	Moisture resistance	40±2℃, 90 to 95%RH for 96h

1. Temperature change experiment	According to the figure below, after 5 cycles, the test was maintained under normal conditions for 30 minutes.
3. Temperature distribution
3. Temperature distribution
Hand welding	welding temperature	Maximum of 260°C
	preheating time	Maximum 60 seconds
	Continuous impregnation time	Maximum 3 seconds
	Welding times	1
