XB-LF-050| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-LF-050-X-X  3D
 Drawings |
 |
Blade switch/blade switch/blade switch normally open and closed/movement blade switch/movement switch/limit switch/reset blade switch/self reset switch/blade switch PUHS ON/blade switch PUHS OFF | 8857 | Normal | Five days/Seven days | 0.36g | 1000 | 1000 | Normal production | Yes |
| product material | 1. Blade switch | Material | ||
| 2.Base material | POM/PA66 | |||
| 3.Terminal | Phosphor copper | |||
| 4. Touch points | brass | |||
| 6.Electroplating | Brass silver plated/brass gold plated | |||
| Electrical properties | Operating temperature range | -10℃±60℃ | ||
| to maximum rating (resistive load) | 0.5A 12V DC | |||
| to minimum rating (resistive load) | 0.1A 6V DC | |||
| Operating force | 30gf±50gf | |||
| Service life | 50,000 times | |||
| Withstand voltage | 500V AC | |||
| Insulation resistance | 100MΩ | |||
| Contact resistance (initial/after life) | 30MΩ | |||
| Durability | No load life | 50,000 times | ||
| Load life (maximum rated load) | 50,000 times | |||
| Environmental resistance | Cold resistance | -40±2°C/96h | ||
| Heat resistance | 80±2°C/96h | |||
| Moisture resistance | 40±2°90 to 95% relative humidity 96/h | |||
| For example, in the environment shown in the icon, after 5 cycles, place it in a normal environment and test after 30 minutes. | No signs of damage to mechanical or electrical performance | |||
|
|
||||
