XB-06-B4AK001| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-06-B4AK001  3D
 Drawings |
 |
28.5 * 16 * 5.5mm button battery holder CR2032/Button cell holder CR1220/CR2032 battery holder/CR1220 button battery holder/button battery holder CR2025/button battery holder CR2045/positive and negative button connector/battery button CR2022 | Normal | 2-4 weeks | 19.000 | 210 pieces/box | 3000 | 10000 | No |
| Product type features | 1. Button battery seat | material quality |
| 2. Plastic | PA10T | |
| 3. Terminal | phosphor copper | |
| 1. Operating temperature range: | -25℃±85℃ | |
| 2. Rated value: | 1A 12V DC | |
| 3. Insulation resistance: | 100MΩ | |
| 4. Voltage resistance: | 500V AC | |
| 5. Contact resistance: | 30MΩ | |
| 6. Life: | 5000 times | |
| structural property | Bullet force at the contact end: | 0.4N-1.2N |
| Resistance to plug and pull: | And 400-600 times / h | |
| Salt Spray Test: | 24±0.5/h | |
| Contact features | Terminal substrate: | Brass silver plated |
| Switch terminal electroplating material: | Silver plated / gold plated | |
| machine accessory | Welding method: | Reflow welding / wave crest welding |
| weldability test: | Bad welding method: | function |
|
|
The tin-stained area at the top of the terminal is required to reach more than 95% | |
| * temperature:235°±5°C | ||
| * Time: 3 ± 0.5 seconds | ||
