Product Material
|
1. D-SUB connector
|
Material
|
|
2. Shell
|
UL94V-0
|
|
3. Terminals
|
Phosphor copper silver plated/Phosphor copper gold plated
|
|
3. Plastic shell
|
Phosphor Bronze
|
|
|
Product Type Features
|
Rated current
|
1A
|
|
Rated voltage
|
250V AC/DC
|
|
Operating temperature range
|
-40°C±85°C
|
|
Contact resistance
|
30mΩ
|
|
Insulation resistance
|
10mΩ
|
|
Withstand voltage
|
1000V AC
|
|
|
Environmental resistance
|
Cold resistance
|
-25±2℃ 96/h
|
|
Heat resistance
|
105±2℃ 96/h
|
|
Moisture resistance
|
35±3℃Relative humidity 90~95% 96/h
|
|
|
Mechanical accessories
|
Installation
|
Wire/Board Welding
|
|
Connector Mounting Type:
|
Board Installation
|
|
|
Solderability test
|
Immerse the terminal pins in the flux for 5 seconds, then immerse the terminal pins in a 230±5℃ tin furnace for 5±0.5 seconds
|
The tin attached area should exceed 95% of the immersed surface area
|
|
|
Solder heat resistance
|
The terminals should be tested for tin resistance and solder heat resistance under the following conditions and then tested for contact impedance.
|
|
Based on: EIA-364-56A
|
No cracks, scratches or breaks
|
|
Solderability temperature: 245°±5C
|
|
Time: 3s+/-0.5s
|
|
Reflow and wave soldering experiments
|
Wave Soldering
|
The recommended soldering temperature for DIP type is 260°C (500°F) for a maximum of 5 seconds
|
|
Hand welding
|
Use a 30W soldering iron to control the temperature at 380°C and solder for about 3 seconds
|
|
Reflow
|
The maximum temperature of the SMT reflow oven is 260°C. When the temperature is 260°C, the maximum time does not exceed 10 seconds.
|
|
|
0769-82056828
XB-CD71-50-S-K0
3D
Drawings
