3D fileXB-DC-012A-5A-2.5 Specifications XB-DC-012A-5A-2.5-
DrawingsXB-DC-012A-5A-2.5

▍Xibang material number：XB-DC-012A-5A-2.5

方向

垂直

安装方式

通孔

外孔

6.4mm

中心引脚

2.5mm

离安装面高度

13.2mm

额定电流

5A

外形尺寸

W13.2xD9.8xH11.0mm

额定电压

24V

屏蔽

否

产品证书

UL/CUL:E523734

3D file and drawings

3D fileXB-DC-012A-5A-2.5 Specifications XB-DC-012A-5A-2.5-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-012A-5A-2.5 3D Drawings		DC connector OD: 6.3xID: 2.5 180 degree PBT	28589	normal	1-2 weeks	0.000	500 pieces/bag	3000	10000	No competitive products	Consult

产品材质	housing:	see table black
	cover:	pa66 black
	pin:	h59 ni-plated
	Terminal:	c2680-eh t=0.35 ag-plated
	Terminal:	c5210-eh t=0.25 ag-plated
	Terminal:	c2680-eh t=0.25 ag-plated

环境条件	Temperature range:	-20 °C/+70 °C

	Mating cycles:	≥ 5000
	Insertion force:	≤ 30 N *1
	Withdrawal force:	3–20 N *2

电气数据	Contact resistance:	≤ 30 mΩ
	Rated current:	5 A
	Rated voltage:	24 V DC
	Rated impulse voltage:	500 V/60 s
