3D fileXB-DC-022M-130 Specifications XB
DrawingsXB-DC-022M-130

▍Xibang material number：XB-DC-022M-130

Product type: DC power Jack Rated current: 1A 3A Rated voltage: 12V 24V DC

Contact resistance: 30m Ω max Withstand voltage: 500 V AC MIN Insulation resistance: 100M Ω min

Life test: 5000 salt spray tests: 24 hours Installation method: plug-in

Plug and pull force: 2-30 N Pull out force: 2-30 N Product certification: ROHS

3D file and drawings

3D fileXB-DC-022M-130 Specifications XB

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-DC-022M-130 3D Drawings		13.9 * 12.9mm DC female base with nut DIP/circular DC socket installation hole 12.8MM/welding wire DC interface outer diameter 13.9MM/buckle DC socket circular with nut/buckle DC socket 3513/DC connector PIN: 1.3/1.65mm		Normal	4~7	0.35	1000 PCS/box	3000 PCS	100000	Nothing	Consult

Product material	1. DC JACK	material quality
	2. The lid	yellow metal
	3. Shrapnel	yellow metal
	4. The base	PBT/PA66/POM
	5. Touch	Brass / silver plated / gold plated
	6. Terminal	Brass / silver plated / gold plated

	Use the temperature range	-30°C±85°C
	Maximum rating (resistance load)	3A 30V
	Minimum rating (resistance load)	1A 12V

Electric performance	withstand voltage	500V AC
	insulation resistance	100mΩ max

lasting quality	No load life	5000 Times
	load life	5000 Times

Environmental resistance	Cold resistance	-40±3℃ for 96h
	resistance to effect of heat	80±2℃ for 96h
	Moisture resistance	40±2℃, 90 to 95%RH for 96h

1. Temperature change experiment	According to the figure below, after 5 cycles, the test was maintained under normal conditions for 30 minutes.
3. Temperature distribution
3. Temperature distribution
Hand welding	welding temperature	Maximum of 260°C
	preheating time	Maximum 60 seconds
	Continuous impregnation time	Maximum 3 seconds
	Welding times	1
