3D fileXB-EC3-2PX Specifications EC3
DrawingsXB-EC3-2PX

▍Xibang material number：XB-EC3-2PX

Product name: EC3 connector Rated current: 25A Rated voltage: 500V DC Rated voltage: 500V DC Load capacity: 20N~50N

Contact resistance:0.8MΩ Use temperature:-40°±120°C Insulation resistance:2000MΩ Use life:5000次 Product code:ROHS

3D file and drawings

3D fileXB-EC3-2PX Specifications EC3

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-EC3-2PX 3D Drawings		16.2 * 17.6 * 7.85mm new energy EC3 banana plug riveting/power supply 2P core male/female seat/wire connection high current 2-core connector EC3/wire end high current 2P plug/power cord 2-core male/female plug/aircraft model EC3 male/female seat/power connector EC3	EC3	Normal	5 days/7 days	0.25g	1000	3000	100000	Nothing	Consult

product material	1.EC3 connector	Material
	2.Hardware	gold plated brass
	3. Plastic shell	PA6
	4.Surface treatment	Gold plating (1μ~3μ)

Electrical properties	Rated current	25A
	Rated voltage	500VDC
	Insertion and extraction force	20N~50N
	Withstand voltage	500VDC
	Insulation resistance	2000MΩ
	Contact resistance (initial/after life)	0.8MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental performance	Operating temperature	-20°C±120°C
Wiring recommendations	AWG	Temperature rise 30K
	18#	25A
