3D fileXB-EC89.5-43 Specifications EC8
DrawingsXB-EC89.5-43

▍Xibang material number：XB-EC89.5-43

Product name: EC8 connector Rated current: 100A Rated voltage: 500V DC Rated voltage: 500V DC Load capacity: 40N～75N

Contact resistance:0.4MΩ Use temperature:-40°±120°C Insulation resistance:2000MΩ Use life:5000次 Product code:ROHS

3D file and drawings

3D fileXB-EC89.5-43 Specifications EC8

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-EC89.5-43 3D Drawings		25 * 28.9 * 14.9mm EC8 male female terminal riveted type/banana head EC8 male female seat/EC8 charging plug/EC8 charging female seat/new energy high current EC8 wiring terminal/lithium battery EC8 connector/EC8 terminal 2P male female seat	EC8	Normal	5 days/7 days	0.25g	1000	3000	100000	Nothing	Consult

product material	1.EC8 connector	Material
	2.Hardware	gold plated brass
	3. Plastic shell	PA6
	4.Surface treatment	Gold plating (1μ~3μ)

Electrical properties	Rated current	100A
	Rated voltage	500VDC
	Insertion and extraction force	40N～75N
	Withstand voltage	500VDC
	Insulation resistance	2000MΩ
	Contact resistance (initial/after life)	0.4MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental performance	Operating temperature	-20°C±120°C
Wiring recommendations	AWG	Temperature rise 60°C
	18#	100A
