▍Xibang material number：XB-NS-1052-X

Product name: Key switch Rated current: 2A 1A Rated voltage: 24V 12V DC Withstand voltage: 1500V AC

Contact resistance: 50MΩ Insulation resistance: 1000MΩ Service life: 50,000 times Working temperature: -25℃±55℃

3D file and drawings

3D fileXB-NS1052 Specifications DIANZI

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-NS-1052-X 3D Drawings		Ø 12mm metal key switch/mechanical electronic lock switch/mechanical lock switch/key lock switch/key lock switch/metal rotary knob switch with key/electronic lock key switch	8857	Normal	Seven days/Ten days	0.85g	500	1000	100000	Yes	Consult

product name	1.Key electronic lock switch	Material
	2.Lock shell	zinc alloy
	3. Lock cylinder	zinc alloy
	4.Key	Hbp59-1
	6. Nuts	zinc alloy
	7.Terminal	silver

Electrical properties	Operating temperature range	-20℃±55℃
	Electrical ratings	2A 24V DC
	Dust/moisture proof	IP40 (return) IP65 (maintain)
	Service life	50,000 times
	Withstand voltage	1500VAC
	Insulation resistance	1000MΩ
	Contact resistance (initial/after life)	50MΩ
	Contact arrangement	SPDT,DPDT
	Maximum panel thickness 10mm mounting nut torque	0.8Nm
