3D fileXB-H25-0323SC-G5H2 (1) Specifications XB-H25-0323SC-G5H2
DrawingsXB-H25-0323SC-G5H2 (1)

▍Xibang material number：XB-H25-0323SC-G5H2

Product name: high-current toggle switch Rated current: 3A Rated voltage: 125V 250V Contact resistance: 100M Ω Circuit: 2P3T

Operating force: 250gf ± 100gf Service life: 10000 times Switch gears: 3nd gear Handle length: 2-12mm Stroke: 4.0mm

Product certificate ROHS

3D file and drawings

3D fileXB-H25-0323SC-G5H2 (1) Specifications XB-H25-0323SC-G5H2

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-H25-0323SC-G5H2 3D Drawings		High current 3nd gear toggle switch High power 3nd gear sliding switch Vertical 3nd gear toggle switch High current 3nd gear sliding switch		Normal	7-10 days	0.00	500	1000	10000	Nothing	Consult

Product material	1.Case	diallyl phthalate (DAP)
	2.Slide Handle	Nylon
	3.Housing	Stainless Steel
	4. Contact	Copper alloy, silver plated
	5.Terminal	Copper alloy, silver plated

	Operating temperature range	-40℃ to 85℃
	Rated power	AC 125v 3A

Electrical performance	Withstand voltage	500V AC for 1 minute
	insulation resistance	100MΩ min. 500V DC
	Contact resistance (at initial stage/after service life)	70mΩ max./130mΩ max.

Durability	No load life	10,000 cycles 100mΩ max.
	Load life (maximum rated load)	10,000 cycles 130mΩ max.

Environmental resistance	Cold resistance	-20℃ 500h
	Heat resistance	85℃ 500h
	Moisture resistance	60℃, 90 to 95%RH 500h

Welding conditions
During immersion welding	Preheat temperature	100℃
	Preheating temperature time	60s max.
	welding temperature	260±5℃
	Immersion time of welding	3±1s

During manual welding	welding temperature	350±10℃
	Welding time	4s max.
