XB-OJ-0001A| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-OJ-0001A-X-X  3D
 Drawings |
 |
10.6 * 4.4 * 18.1mm optical fiber connector transmitter/optical fiber socket transmitter/optical fiber socket receiver/optical fiber socket receiver/optical fiber socket/optical fiber interface/optical fiber socket transmitter and receiver | Normal | 5 days/7 days | 0.36g | 1000 | 3000 | 10000 | Yes |
| product material | 1. Optical fiber transmitter | Material |
| 2. Shell | PBT/UL94 V-0 | |
| 3. Door | PBT/UL94 V-0 | |
| 4.Spring | SUS | |
| 5. cover | PBT | |
| Operating temperature range | -20°C±70°C | |
| Maximum rating (resistive load) | 14mA 5.5V | |
| Minimum rating (resistive load) | 8mA 2.7V | |
| Electrical properties | Withstand voltage | 500V AC |
| Insulation resistance | 100mΩmax | |
| Insertion and extraction force | 3N~40N | |
| Contact resistance | ≤0.03Ω | |
| Durability | No load life | 5000 times |
| load life | 5000 times | |
| Resistant to welding heat | 260°±5°C | |
| Electrical and optical properties | Emitter wavelength | 670nm |
| emit light energy | -21/-15dBm | |
| Delay | 100ns | |
| data speed | 25/Mbps | |
| Transmission distance | 20m | |
