XB-B10-M6| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-B10-M6  3D
 Drawings |
 |
6P female high-power 6PIN knife type battery holder, 6-position blade battery connector, 6-position battery, with a spacing of 7.5mm between male and female seats | Normal | 4~7 | 0.5 | 500 | 30000 | 10000 | Nothing |
| product name | 1. Blade battery connector | PA9T UL94V-0 |
| 2. Cover | Copper Gold-plated C5191 | |
| 3. The foundation | PA9T UL94V-0 | |
| 4. Contact the film | bronze | |
| 5. Terminal | Brass gold plated | |
| Use the temperature range | -40℃～105℃ | |
| Maximum rating (resistance load) | 7A DC | |
| Minimum rating (resistance load) | 24V DC | |
| Electric performance | withstand voltage | 500V AC for 1 minute |
| insulation resistance | 100MΩ 500V DC | |
| Contact resistance (initial / post-life) | 30mΩ max./100mΩ max. | |
| lasting quality | No load life | 5000 Times |
| Load life (maximum rated load) | 5000 Times | |
| Environmental resistance | Cold resistance | -20℃ 500h |
| resistance to effect of heat | 85℃ 500h | |
| Moisture resistance | 60℃, 90 to 95%RH 500h | |
| welding condition | ||
| When immersed in welding | preheat temperature | 100℃ |
| Preheat temperature time | 60s max. | |
| welding temperature | 260±5℃ | |
| Welding impregnation time | 3±1s | |
| Hand welding | welding temperature | 350±10℃ |
| weld period | 4s max. |
