▍Xibang material number：XB-RS-603A-X

Product type: Rocker switch Rated current: 12A 16A AC Rated voltage: 125V 250V AC Contact resistance: 30m Ω max

Voltage resistance: 1500V Insulation resistance: 100 M Ω min Life test: 10000 times Working temperature: -10 ℃ ± 105 ℃

Plastic: PA66 Pin Material: Brass Welding Waterproof: Solder Wire/Solder Plate Product Compliance: UL.VDE.ROHS

3D file and drawings

3D fileXB-RS-603A Specifications XB-KCD5-06A-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-RS-603A-X 3D Drawings		26 * 12.5 * 12.4mm electric wind blowing rocker switch 16A125V/electric hair blowing power switch 2nd gear 3rd gear/electric wind blowing switch/electric hair blowing switch/third gear ship type switch high current 16A		Normal	7-15 days	0.3g	1000	5000	1000	Nothing	Consult

Product type features	1. Ship type switch	material quality
	2. Button	PA66
	3. Shell	Nylon / PA66 / 94V-0~2
	4. The base	PA66
	5. Feet	Brass silver plated

	1. Operating temperature range:	-10℃±105℃
	2. Rated value:	12A 16A 125V 250AC
	3. Insulation resistance:	100MΩ
	4. Voltage resistance:	1500V AC
	5. Contact resistance:	30MΩ
	6. Life:	10000 Times

structural property	Operation force:	5N~9N
	Terminal strength:	80N
	Salt Spray Test:	35±0.2°C 24/h

Environmental resistance	Cold resistance	-20±2℃ 96/h
	resistance to effect of heat	105±2℃ 96/h
	Moisture resistance	40 ± 2℃ relative humidity 90~95% 96 / h
