3D fileXB-EST-M07-535SSERIES Specifications SATA连接器规格书
DrawingsXB-EST-M07-535SSERIES

▍Xibang material number：XB-EST-M07-535SSERIES-X

Product type: Sata connector Rated current: 1.5A Rated voltage: 5V 12V DC Withstand voltage: 500V AC

Insertion and extraction force: 10N-45N Contact resistance: 30m Ω max Insulation resistance: 100 M Ω min Service life: 5000 times

Plastic material: LCP shell: SUS stainless steel/copper terminal electroplating: silver plating/gold plating Working temperature: -25 ℃~+85 ℃

Installation method: Solder board Welding method: SMD/DIP Packaging method: Plate mounted products comply with ROHS

3D file and drawings

3D fileXB-EST-M07-535SSERIES Specifications SATA连接器规格书

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-EST-M07-535SSERIES-X 3D Drawings		18.7X13.65X7.7mm horizontal SATA socket SMD/horizontal SATA socket Smt/SATA female seat horizontal Smd/SATA socket 7PIN/hard disk side SATA interface 7PIN/laptop SATA socket ESATA 7PIN R/A SMT	Sata connector	Normal	1-2 weeks	0.45g	1000 PCS/disk	30000 PCS/disk	100000	No competitors	Consult

product material	1.Sata connector	Material
	2.Contact	copper alloy
	3.Plastic	LCP/UL94V-0
	4.Terminal	copper alloy
	5. Shell	Brass silver plated

Electrical properties	Rated current	1.5A
	Rated voltage	12VAC
	Insertion and extraction force	10N-45N
	Withstand voltage	500VAC
	Insulation resistance	100MΩ
	Contact resistance (initial/after life)	30MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental resistance	Cold resistance	-40±2℃ for 48h
	Heat resistance	85±2℃ for 48h
	Moisture resistance	40±2℃, 90 to 95%RH for 48h

Weldability	Immerse the soldering terminals into velvet tin at 235°C for 3±0.5s with a minimum immersion depth of 2mm.	More than 95% of the surface of the tin-immersed part must be well dipped in tin

Resistant to reflow heat	Preheating: 150°C~180°C 90±30s Heating 230°C 30±10s Heating peak 260°CMAX: 20s~40s	The appearance should be free of damage, the terminals should not be loose, and the plastic should not be deformed.
