3D fileXB-SIM-102011232 Specifications XB-Smart CARD
DrawingsXB-SIM-102011232

▍Xibang material number：XB-SIM-102011233

Product type: NANO SIM card holder Rated current: 0.5A Rated voltage: 30V 50V

Contact resistance: 50m Ω max withstand voltage: 500 V AC MIN insulation resistance: 1000 M Ω min

Life test: 5000 times Installation method: surface mount product certification: ROHS

3D file and drawings

3D fileXB-SIM-102011232 Specifications XB-Smart CARD

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SIM-102011233 3D Drawings		SIM card holder/SIM CARD PUSH external welding H=1.80 LCP black glue terminal C5210 shell stainless steel/SIM connector/SIM card holder NANO/NANO SIM card holder/card holder connector		Normal	1-2 weeks	0.5	1000	10000	10000	No competitive products	Consult

产品材质	SIM card holder connector	LCP UL 94V-0 Color:WHITE
	Terminal	COPPER ALLOY t=0.12mm
	Shell	SPCC/BRASS t=0.20mm

产品类型特性	卡类型:	SD CARD
	连接器和端子端接到:	印刷电路板
	端子数量:	8
	寿命:	5000次

接触件特性	端子基材:	选择性镀银
	端子额定电流（最大值）(A):	0.5A

壳体特性	中心线（间距）:	1.2mm 1.3mm 1.7mm 2.43

机械附件	PCB 安装方式:	表面贴装
	连接器安装类型:	板安装

使用环境	工组温度范围:	-40°C ~+ 85°C
