3D fileXB-SIM-0211BAAG06ASERIES Specifications SIM
DrawingsXB-SIM-0211BAAG06ASERIES

▍Xibang material number：XB-SIM-0211BAAG06ASERIES-X

Product type: SiM card holder connector Rated current: 0.5A Rated voltage: 5V 12V DC Withstand voltage: 500V AC

Insertion and extraction force: 0.3N-0.9N Contact resistance: 30m Ω max Insulation resistance: 100 M Ω min Service life: 5000 times

Plastic material: LCP/PA spring material: SUS304 shell: SUS stainless steel terminal electroplating: silver/gold plating

Working temperature: -25 ℃~+85 ℃ Installation method: Surface mount Packaging method: 1000PCS/Reel Product compliance: ROHS

3D file and drawings

3D fileXB-SIM-0211BAAG06ASERIES Specifications SIM

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SIM-0211BAAG06ASERIES-X 3D Drawings		19.3x26.54x1.7mm SIM socket Card 6+2 Pin/SIM connector Card 6+2 Pin/SIM socket Card 6+2 Pin/SIM female socket	SIM card holder/SIM connector	Normal	1-2 weeks	0.42g	1000 PCS/disk	30000 PCS/box	10000	No competitors	Consult

product material	1.Sim card holder/SIM connector	Material
	2.Plastic	LCP/PA/UL94V-0
	3. High temperature resistant materials	LCP/PA/UL94V-0
	4.Terminal	copper alloy
	5. Shell	SUS

Electrical properties	Rated current	0.5A DC
	Rated voltage	5V 12V DC
	Insertion and extraction force	0.3N-0.9N
	Withstand voltage	500VAC
	Insulation resistance	1000MΩ
	Contact resistance (initial/after life)	30MΩ

Durability	No load life	5000 times
	Load life (maximum rated load)	5000 times

Environmental resistance	Cold resistance	-40±2℃ for 48h
	Heat resistance	85±2℃ for 48h
	Moisture resistance	40±2℃, 90 to 95%RH for 48h

Weldability	Immerse the soldering terminals into velvet tin at 235°C for 3±0.5s with a minimum immersion depth of 2mm.	More than 95% of the surface of the tin-immersed part must be well dipped in tin

Resistant to reflow heat	Preheating: 150°C~200°C 60~120s Heating 217°C 60s Heating peak 260°CMAX: 5s~10s	The appearance should be free of damage, the terminals should not be loose, and the plastic should not be deformed.
