| Product Center > Switch > Slide Switch > High current Slide Switch > High current side switch 2P10T

Scan code to browse

3D fileXB-T-K1011-11P Specifications XB-SK3.6
DrawingsXB-T-K1011-11P

▍Xibang material number：XB-T-K1011-11P

Product name: toggle switch Rated current: 3A 6A Rated voltage: 125V 250V Withstand voltage: 500V

Contact resistance: 30MΩ Service life: 10,000 times Operating strength: 450gf±150gf Handle length: 2-10mm

Base/handle: PPA/PA10T/POM Contact piece: brass Pin material: yellow silver-plated/gold-plated Installation method: welding

3D file and drawings

3D fileXB-T-K1011-11P Specifications XB-SK3.6

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-T-K1011-11P 3D Drawings		55 * 10.5 * 8.4mm side dial ten speed sliding switch 1P10T/horizontal high current ten speed dip switch bent foot 1P10T/side handle ten speed toggle switch eleven foot/high-power ten speed sliding switch horizontal/horizontal handle ten speed toggle switch 11PIN	Side shift toggle	Normal	4-7 days	0.3g	500	2000	10000	No competitors	Consult

product material	1. Toggle switch	Material
	2.Plastic	PPA/PA10T/PA66
	3.Contact sheet	brass
	4.Button	POM
	5. Pin	Brass silver plated/brass gold plated
	6.Spring	SUS304

Electrical properties	Operating temperature range	-10℃±60℃
	Maximum rating (resistive load)	6A 125V AC
	Minimum rating (resistive load)	3A 250V AC
	Operating force	450gf±150gf
	Withstand voltage	500VAC
	Insulation resistance	100MΩ
	Contact resistance (initial/after life)	30MΩ

Durability	No load life	10000 times
	Load life (maximum rated load)	10000 times

Environmental resistance	Cold resistance	-40±3°C/96h
	Heat resistance	70±2°C/48h
	Moisture resistance	40±2°90 to 95% relative humidity 96/h

Temperature alternating test
For example, in the environment shown in the icon, after 5 cycles, place it in a normal environment and test after 30 minutes.		No signs of damage to mechanical or electrical performance

Solderability test		More than 95% of the surface of the immersed part will be covered with tin
	The top of the terminal is immersed in the solder pool 2mm deep, the temperature is 240±5°C, and the time is 3 seconds. Lead-free tin test: composition: tin 96.5%, copper 3%, silver 0.5%
Solder resistance test	When hand welding, the temperature needs to be controlled at 360±10℃ and the time is 3±0.5 seconds, but abnormal pressure cannot be applied to the terminals. Lead-free tin test: Ingredients: 96.5% tin, 3% copper, 0.5% silver	The body has no deformation and can meet the mechanical and electrical performance
