3D fileXB-TM-VS-040P Specifications XB-TM-036-S-
DrawingsXB-TM-VS-040P

▍Xibang material number：XB-TM-VS-040P

Product Name: Detection Switch Rated Current: 0.1A 0.3A Rated Voltage: 12V 24V DC Structure Function: Self resetting

Insulation resistance: 100M Ω Contact resistance: 30 Ω Voltage endurance: 100V Terminal electroplating: brass silver plated

Welding method: wave soldering/reflow soldering Service life: 10000 times Operating force: 100gf ± 30gf Circuit principle: normally open/normally closed

3D file and drawings

3D fileXB-TM-VS-040P Specifications XB-TM-036-S-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-TM-VS-040P 3D Drawings		Touch switch SMT/reset switch/three position limit switch/vertical detection switch/small detection switch/detection normally open switch/detection normally closed switch 4PIN		Normal	4-7 days	0.3g	500	2000	10000	No competitive products	Consult

Product material	1. Detection Switch	material quality
	2. The base	PA66
	3. Spring	SUS
	4. Leverage	SUS
	5. Button	POM
	6. The lid	POM
	7. Welding feet	Brass silver plated

Electric performance	Use temperature range (standard)	-10℃±60℃
	Service temperature range (vehicle)	-40℃±85℃
	Maximum rating (resistance load)	0.3A 30V DC
	Minimum rating (resistance load)	0.1A 12V DC
	Operation force	100gf±30gf
	withstand voltage	100V AC
	insulation resistance	200MΩ min
	Contact resistance (initial / post-life)	100MΩ

lasting quality	No load life	50000 Times
	Load life (maximum rated load)	50000 Times

Environmental resistance	Cold resistance	-40℃/500h
	resistance to effect of heat	85℃/500h
	Moisture resistance	60℃, 90 to 95% relative humidity for 500h

Temperature cross-change test
In the environment of the icon, cycle 5 times, then put in the normal environment, and test after 30 minutes		No indication of any damage to the mechanical and electrical properties

welding condition
When automatically immersed in welding	preheat temperature	Up to 100℃
	Preheat temperature time	Maximum 60 seconds
	welding temperature	255±5℃
	Welding impregnation time	5 ± for 1 second

Hand welding	welding temperature	350±5℃
	weld period	Maximum 5s
