| Product Center > Socket > Bullet battery holder > Side pressure type > Spacing 5.0

Scan code to browse

3D fileXB-BC-75-3PD800 Specifications 弹片电池座子规格书
DrawingsXB-BC-75-3PD800

▍Xibang material number：XB-BC-75-3PD800

Product name: Fragment Battery holder Rated current: 1A 3A Rated voltage: 12V 60V Contact resistance: 30M Ω

Insulation resistance: 100M Ω Plastic: LCP/PA66 Elastomer material: Phosphorus copper C5210 Voltage resistance: 500V

Service life: 5000 times Weldability: 260 ± 5 ℃, working temperature: -40 ℃ ± 85 ℃ Product meets: ROHS

3D file and drawings

3D fileXB-BC-75-3PD800 Specifications 弹片电池座子规格书

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-BC-75-3PD800 3D Drawings		7.5 * 4.3 * 8.0mm shrapnel battery holder/side press type shrapnel battery holder plastic height: 8.0mm/shrapnel battery holder male seat 3P/shrapnel battery spacing: 5.0mm/shrapnel connector 3PIN		Normal	4~7 days	0.000	5000	50000	10000	No competitive products	Consult

product name	1. Shrapnel battery holder	material quality
	2. The shell	LCP/PA66 UL 94-V
	3. Touch	Brass Gold plated / Brass C2680
	5. Plastic parts	LCP/PA10T

character of service	Use the temperature range	-40℃±85℃
	Maximum rating (resistance load)	3A 60V DC
	Minimum rating (resistance load)	1A 12V DC

Electric performance	withstand voltage	500V AC
	insulation resistance	100MΩ
	Contact resistance (initial / post-life)	30mΩ max./100mΩ max.

lasting quality	No load life	5000 Times
	Load life (maximum rated load)	5000 Times

project	test condition	function
Cold resistance	-40℃±3°C 96/h	No indication of any damage to the mechanical and electrical properties
resistance to effect of heat	80℃±2°C 96/h
Moisture resistance	40℃± 2°C, 90 to 95% RH 96 / h
Salt mist performance	35°C ± 2°C 4h ± for 15 sec
Temperature alternating experiment:	Like the icon, in the environment, cycle 5 times, then placed in the normal environment, and test after 30 minutes.


Thermal test for return heat welding:	test condition	function
		The body has no deformation, and can be satisfied with the mechanical and electrical performance
* Temperature refers to the temperature of the PC plate surface
* The PC plate is 1.0 mm thick
No lead tin test
Ingredients: tin 96.5% copper 3% silver 0.5%
Number of reflow welding: 1 time
