▍Xibang material number：XB-BC-72-4PD190

Product name: shrapnel battery holder Rated current: 5A Rated voltage: 12V Contact resistance: 100M Ω Plastic: LCP

Fragment material: phosphor bronze C5210 Service life: 3000 times Weldability: 260 ± 5 ℃, withstand voltage: AC 500V Product certification: ROHS

3D file and drawings

3D fileXB-BC-72-4PD190 Specifications 弹片规格书

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-BC-72-4PD190 3D Drawings		Bullet battery holder 4PIN/mobile phone battery holder/bullet connector mother holder/bullet battery holder spacing: 4.0mm/high-efficiency battery connector		Normal	4~7 days	0.000	5000	50000	10000	No competitive products	Consult

Product material	1.Keystake	PA46
	2.cover	SUS Tin plated
	3.Base	LCP
	4. Contact spring	Beryllium copper
	5.Terminal	Brass（0.30t） ag Plated

	Operating temperature range	-40℃ to 85℃
	Maximum rating (resistive load)	0.3A 4V DC
	Minimum rating (resistive load)	50A 3V DC

Electrical performance	Withstand voltage	500V AC for 1 minute
	insulation resistance	100MΩ min. 500V DC
	Contact resistance (at initial stage/after service life)	70mΩ max./130mΩ max.

Durability	No load life	10,000 cycles 100mΩ max.
	Load life (maximum rated load)	10,000 cycles 130mΩ max.

Environmental resistance	Cold resistance	-20℃ 500h
	Heat resistance	85℃ 500h
	Moisture resistance	60℃, 90 to 95%RH 500h

Welding conditions
During immersion welding	Preheat temperature	100℃
	Preheating temperature time	60s max.
	welding temperature	260±5℃
	Immersion time of welding	3±1s

During manual welding	welding temperature	350±10℃
	Welding time	4s max.
