XB-PS102-201001R1B-3D-ZP| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-PS102-201001R1B-3D-ZP  3D
 Drawings |
 |
21 * 15.1 * 17.2mm square power supply self-locking switch 16A/self-locking button switch high current 10A/high-power light touch switch 125V/high current button switch ON OFF 250V AC/power switch 10A AC/self-locking switch high current 10A4PIN | Normal | 4~7 days | 0.000 | 500 | 50000 | 10000 | No competitive products |
| Product material | 1. Button switch | material quality |
| 2. Button | PA66 | |
| 3. The crochet | SUS | |
| 4. The bottom plate | PA66 | |
| 5. The shell | PA66 | |
| 6. Terminal | Brass silver plated | |
| 7. Contact the bridge | Brass silver plated | |
| Use the temperature range | -10℃±105℃ | |
| Operation force | 9N~13N | |
| Maximum rating (resistance load) | 10A/15A 250V AC | |
| Minimum rating (resistance load) | 3A/5A/7A 125V AC | |
| Electric performance | withstand voltage | 1500V AC |
| insulation resistance | 100MΩ min.500V DC | |
| Contact resistance (initial / post-life) | 30mΩ max | |
| lasting quality | No load life | 10,000 times 100 mΩ max. |
| Load life (maximum rated load) | 10,000 times 100 mΩ max. | |
| Environmental resistance | Cold resistance | -20±2℃ 96h |
| resistance to effect of heat | 105±2℃ 96h | |
| Moisture resistance | 40℃±2℃ 90~95%RH 96h | |
| Automatic welding conditions | preheat temperature | - |
| preheating time | - | |
| welding temperature | 250±5℃ | |
| weld period | 3 ± 0.5 seconds | |
| Manual welding conditions | welding temperature | 300℃±10℃ |
| weld period | 3 ± 0.5 seconds | |
| Iron power | 60 Watts | |
