▍Xibang material number：XB-SS12D07L2B

Product Name: Slide Switch Rated Current: 0.3A Rated Voltage: 50V Contact Resistance: 30m Ω max

Withstand voltage: 500 V DC MIN circuit: 1P2T Service life: 10000 times Operating force: 250gf ± 100gf

Number of switch gears: 3. Handle length: 2-10mm Stroke: 2mm Product certificate: ROHS

3D file and drawings

3D fileXB-SS12D07LXB Specifications XB-SS12D07LXB-

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-SS12D07L2B 3D Drawings		Toggle switch, vertical straight foot two gear, plug-in, single row high temperature salt spray resistant for 24 hours, 8.6x4.5x4.7 flat black handle 2mm	9884	Normal	1-2 weeks	0.459	2000 pieces/bag	6000	10000	No competitive products	Consult

Product material	1.Keystake	PA46
	2.cover	SUS Tin plated
	3.Base	LCP
	4. Contact spring	Beryllium copper
	5.Terminal	Brass（0.30t） ag Plated

	Operating temperature range	-40℃ to 85℃
	Maximum rating (resistive load)	0.3A 4V DC
	Minimum rating (resistive load)	50A 3V DC

Electrical performance	Withstand voltage	500V AC for 1 minute
	insulation resistance	100MΩ min. 500V DC
	Contact resistance (at initial stage/after service life)	70mΩ max./130mΩ max.

Durability	No load life	10,000 cycles 100mΩ max.
	Load life (maximum rated load)	10,000 cycles 130mΩ max.

Environmental resistance	Cold resistance	-20℃ 500h
	Heat resistance	85℃ 500h
	Moisture resistance	60℃, 90 to 95%RH 500h

Welding conditions
During immersion welding	Preheat temperature	100℃
	Preheating temperature time	60s max.
	welding temperature	260±5℃
	Immersion time of welding	3±1s

During manual welding	welding temperature	350±10℃
	Welding time	4s max.
