XB-PBM-19-11M-F-NNN-S0-S| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-PBM-19-11M-F-NNN-S0-S-X-X  3D
 Drawings |
 |
High current metal switch Ø 19/metal button switch Ø 19/metal button switch/metal self-locking switch ON OFF/metal light touch switch PUHS ON/metal switch Ø 19mm | Metal button switch | Normal | 7 days/15 days | 0.5g | 1000 | 1000 | 1000 | Yes |
| product material | 1. Metal button switch | Material | ||
| 2. Actuator | PA66 | |||
| 3. Base | PA66/POM | |||
| 4. Base | PA66/GF | |||
| 5.Terminal | Brass silver plated/brass gold plated | |||
| 6.Spring | SUS304 | |||
| 7. Nuts | Brass/silver plated/nickel plated | |||
| 8.Gasket | Brass/silver plated/nickel plated | |||
| Electrical properties | Operating temperature range | -20℃±70℃ | ||
| to maximum rating (resistive load) | 5A 250V AC | |||
| to minimum rating (resistive load) | 2A 36V DC | |||
| Withstand voltage | 1500VAC | |||
| Insulation resistance | 100MΩ | |||
| Contact resistance (initial/after life) | 50MΩ | |||
| Structural properties | Operating functions: ON OFF / PUHS ON | Off (on) Self-locking/unlocked | ||
| Configuration (extreme throw): | Single Pole - Double Throw | |||
| Actuator type: | Rubber handle | |||
| Actuator direction: | touch | |||
| Number of actuators: | 1 | |||
| Durability | No load life | 10000 times | ||
| Load life (maximum rated load) | 10000 times | |||
| Environmental resistance | Cold resistance | -20±2°C/96h | ||
| Heat resistance | 85±2°C/96h | |||
| Moisture resistance | 40±2°90 to 95% relative humidity 96/h | |||
