Material
Contact Material: Phosphor Bronze
Standard Insulator Material: LCP
Housing Material: LCP (UL94V-0), White /Natural
Actuator Material: LCP (UL 94V-0), Black
Plating
Underplating: Nickel
Contact Plating: Tin or Gold Flash
Fitting Nail: Brass, tin plated
Electrical
Voltage Rating: 30V AC/DC
Current Rating: 0.2A AC/DC
Contact Resistance: 40mΩ Max.
Insulation resistance: 50MΩ Min. 250 V DC for 1 minute between adjacent terminal
Dielectric withstanding voltage: 250V AC for 1 minute between adjacent terminal, no breakdown
Mechanical
Durability: 20 Cycles
Mating Force: ZIF
Applicable Wire Range: 0.3mm thick
Environmental and Processing
Operating Temperature: -25°C to +85°C
Solder Temperature: Peak temp 260°C (+0/-5°C) Maximum (5 seconds)
