▍Xibang material number：XB-NS-102-2

Product name: Key switch Rated current: 2A 1A Rated voltage: 24V 12V DC Withstand voltage: 1500V AC

Contact resistance: 50MΩ Insulation resistance: 1000MΩ Service life: 50,000 times Working temperature: -25℃±55℃

3D file and drawings

3D fileXB-NS102-2 Specifications DIANZI

Part number information
Technical Features
Technical Drawings
Product Specifications

Product ID	Product Image	Product Description	Product Code	Production status	Shipping Cycle	Gross item weight	MPQ	MOQ	Production in transit	Competitive purchases	Operation
XB-NS-102-2 3D Drawings		Ø 12mm metal key switch/mechanical electronic lock switch/mechanical lock switch/key lock switch/key lock switch/metal rotary knob switch with key/electronic lock key switch	8857	Normal	Seven days/Ten days	0.85g	500	1000	100000	Yes	Consult

产品名称	1.钥匙电子锁开关	材质
	2.锁壳	锌合金
	3.锁芯	锌合金
	4.钥匙	Hbp59-1
	6.螺母	锌合金
	7.端子	镀银

电性能	使用温度范围	-20℃±55℃
	电气额定值	2A 24V DC
	防尘/防潮	IP40 (返回）IP65 （保持）
	使用寿命	50000次
	耐电压	500V AC
	绝缘电阻	1000MΩ
	接触电阻(初期/寿命后)	50MΩ
	触点布置	SPDT、DPDT
	最大面板厚度10mm安装螺母扭矩	0.8Nm
