XB-D01N-A-5P-R1| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-D01N-N-5P-X  3D
 Drawings |
 |
18.5 * 5 * 3.5mm5P male/blade connector/blade socket/high-power blade battery holder/blade battery connector/battery male/female socket spacing: 3.0mm | Normal | 4~7 | 0.5 | 500 | 30000 | 10000 | Nothing |
| product name | 1.Blade male battery connector | PA9T UL94V-0 |
| 2. Cover | Copper Gold-plated C5191 | |
| 3. The foundation | PA9T UL94V-0 | |
| 4. Contact the film | bronze | |
| 5. Terminal | Brass gold plated | |
| Use the temperature range | -40℃～105℃ | |
| Maximum rating (resistance load) | 15A 60V DC | |
| Minimum rating (resistance load) |
12A 12V DC |
|
| Electric performance | withstand voltage | 500V AC for 1 minute |
| insulation resistance | 100MΩ 500V DC | |
| Contact resistance (initial / post-life) | 30mΩ max./100mΩ max. | |
| lasting quality | No load life | 5000 Times |
| Load life (maximum rated load) | 5000 Times | |
| Environmental resistance | Cold resistance | -20℃ 500h |
| resistance to effect of heat | 85℃ 500h | |
| Moisture resistance | 60℃, 90 to 95%RH 500h | |
| welding condition | ||
| When immersed in welding | preheat temperature | 100℃ |
| Preheat temperature time | 60s max. | |
| welding temperature | 260±5℃ | |
| Welding impregnation time | 3±1s | |
| Hand welding | welding temperature | 350±10℃ |
| weld period | 4s max. |
